Equipment model |
BGKJ-36002200Q |
Laminated area |
3.6m×2.2m |
|
Dimensions |
12m×3.1m×1.8m |
equipment weight |
11T |
|
power supply |
AC380V3 phase 5 lines |
Peak power consumption |
68KW |
|
Vacuum pump rate |
70L/S |
Normal working power consumption |
20KW |
|
control method |
automatic / manual |
Ultimate vacuum |
20Pa |
|
heating method |
SD320 heat transfer oil heating |
Temperature control mode |
Self - tuning intelligent PID control |
|
The highest temperature of the table |
180℃ |
Temperature uniformity |
± 1.5 ℃, multi-point temperature control |
|
Operating temperature range |
100～180℃ |
Temperature controllable accuracy |
≤±1℃ |
